Reading the Panel.
I N S E R T C A R T R I D G E
The Z-DSP front panel contains graphics and
typography to help you understand the signal flow and
to indicate the functions of the knobs and jacks.
Some shortcuts used are:
FEDBK or FDBK Feedback
VCP1 Voltage control digital Parameter 1
VC-PRG Voltage Controlled Program
FWD/REV Forward/ Reverse
I/O In / Out
From top-to-bottom/left-to-right the panel contains:
• LCD display
• Audio inputs jacks and knobs
• DSP parameter control knobs
• Feedback input jacks and knobs
• DSP parameter control CV inputs
• Clock/Sample rate jack
• An audio clipping led indicator
• Audio and Feedback Output jacks
• DSP cartridge socket
• A Wet/Dry knob and CV jack
• A program select switch along with 3
jacks for sequential program switching
using either VC or trigger/gate signals
In total there are 8 pots and 18 jacks.
