4
A plug-in Phoenix terminal block on the rear panel accommodates the remote control
connections and also the low-voltage outputs. There are three inputs which control power state;
one programmable 12V dc output; and one programmable auxiliary relay providing normally-
open contacts. The inputs can be controlled by an applied DC voltage from 5V to 30V, by a
contact closure, or by different types of switch; the input selection being made during
programming. The inputs and 12V output are designed to withstand incorrect connections
including polarity reversal and shorts.
2 Features
• Unsurpassed SurgeX ®
Advanced Series Mode
®
• SurgeX
surge elimination
®
Impedance Tolerant
®
• SurgeX
EMI/RFI filtering
®
ICE
®
• All functions easily programmed from the front panel
Inrush Current Elimination
• Accepts both DC voltage and contact closure control inputs
• Two or more units can be ganged or cascaded together for larger systems
• Programmable auxiliary relay output can be used to control other SurgeX
®
• Programmable 12 Volt dc output can be used to control other SurgeX
products
®
• Auxiliary relay or 12 Volt dc output can be programmed to provide confirmation feedback
products or drive
LEDs
• Built-in AC Voltmeter
• Built-in AC Ammeter
• Built-in Power Calculation
• Separate over-ride input can be used to force unit off or force unit on
• Adjustable under-voltage and over-voltage shut-down
• Optional restore after power failure feature
3 Installation
The SurgeX XR315 is designed to rest on a flat surface or to be installed in a 19 inch equipment
rack and requires one unit (1-U) of rack space. To place the XR315 on a flat surface, use four
6-32 Phillips pan head screws (included) to attach the four decorative feet (included). To install
in an equipment rack, use eleven 6-32 Phillips flat head screws (included) to attach the
removable rack-mounting brackets (included) to the sides of the product. Use the four
thumbscrews provided with the product to secure the rack ears to the rack rails. These screws can
be tightened by hand and do not require tools. Connect power to the unit by plugging the cord
into a 120V ac, 15 amp wall or floor receptacle. Do not plug the unit into a relocatable power
