9
Specifications
Operational Voltage Range:
90 to 150 Volts AC
Current rating:
15 Amps
Power Rating:
1,800 Watts
Maximum Load Inrush Energy:
1400 Joules total during power-up
Surge Let-through Voltage:
Zero let-through Voltage for a 6000 Volt surge
Meets Federal Guidelines:
Grade A, Class 1, Mode 1 (CID A-A-55818)
EMI/RFI Filter, Normal Mode:
40 dB @ 100 KHz, 50dB @ 300 KHz, 50 dB @ 3 MHz, 50 dB @ 30
MHz (50 Ohm load)
EMI/RFI Filter, Common Mode:
18dB @ 300 KHz, 30 dB @ 1 MHz, 50 dB @ 5 MHz, 50 dB @ 20
MHz (50 Ohm load)
Maximum Applied Surge Voltage:
6,000 Volts *
Maximum Applied Surge Current:
Unlimited (due to current limiting) *
Maximum Applied Surge Energy:
Unlimited (due to current limiting) *
Endurance:
(C62.41-1991 category B3 pulses), 1 KV > 500,000;
3 KV > 10,000; 6 KV > 1000
Number of Outlets:
8
Remote Control Voltage:
5 to 30 Volts dc
Remote Control Current Draw:
4 mA maximum
Contact Closure Max. Resistance:
100 Ohms
Auxiliary Relay Contact Rating:
30 Volts dc at 1 Amp
12 Volt Output Max. Current:
40 mA
AC Voltmeter Accuracy:
± 2%
AC Ammeter Accuracy:
0.1A resolution, ±1A accuracy
Coax Protection:
Compatible with Cable Television (CATV), Digital Satellite System
(DSS), Television, Video Cassette Recorder (VCR), Cable Modem,
and TV Antenna Equipment. Approvals: UL 497B, UL Recognized.
Dimensions (no rack ears or feet): 17.3” W x 10.5” D x 1.7” H
Weight: 12 lbs (5.4kg)
Temperature Range: 5C to 35C
Humidity Range: 5% to 95% R.H. Non-condensing
Agency Listings: ETL and cETL (UL 1449, Third Edition, Type 3 Surge Protective Device; UL 1283;
CSA C22.2 No.8-M1986, R2004)
* 1.2 x 50 microsecond industry standard combination wave surge as per IEEE C62.41
