DX150-ZIPKIT Installation 3
DX150-ZIPKIT User's Guide - Rev. A01 StorCase Technology, Inc.
0616
Drive
(Not Included)
M3 x 5MM
Screws (4 ea.)
Drive Bracket
Drive Sits Flush with Drive
Bracket Filler Panel
0615
Zip Drive
Rear Panel
Power
Connector
(Red)
ID Select
Cable (Black)
I/O Connector
(Pin 1)
Data Express
Carrier Board
ID Select
Cable (Black)
Figure 4: Connecting the ID Select Cable
Figure 3: Installing the Drive Into the Bracket
5. Attach the drive to the adapter bracket using four (4) M3 screws, as shown in Figure
3.
6. Attach the Power Cable Adapter (included) to the Data Express power cable (Figure 1).
7. Attach the ID select cable (included - Figure 4), the I/O and power cables to the drive.
Refer to the Data Express User's Guide and the drive manufacturer's documentation for
information on these procedures.
