SATA DE75 User's Guide - Rev. A00 StorCase Technology, Inc.
Installation 9
5. Connect the I/O cable from the host adapter to the receiving frame.
6. Connect the power cable from the DC power supply in the computer or expansion
chassis to the power connector on the SATA DE75 “universal” receiving frame.
Refer to Figure 4 for the SATA DE75 “universal” receiving frame power
connector location.
7. Replace any expansion boards that may have been removed earlier. Replace the
system cover according to the manufacturer’s instructions.
8. Reconnect any system or peripheral cables removed earlier.
9. Turn ON power to the computer. If the installation has been successful, and all the
cables have been properly attached, the system should boot normally. Although the
computer may not recognize the SATA DE75 yet, the front panel display on the SATA
DE75 receiving frame should illuminate.
10. The new drive may need to be formatted or initialized prior to use with the operating
system and applications software. Refer to the drive and/or computer manufacturer's
documentation for formatting information.
