Appendix A - Specifications/Dimensions 17
DX115 for Backup User's Guide - Rev. A01 StorCase Technology, Inc.
Figure A-1: SATA 3Gbps DX115 Physical Dimensions
(Dimensions are for reference only)
Receiving Frame
with Carrier
Installed
Carrier
Only
4.43
(112.5mm)
1.07
(27.2mm)
4.43
(112.5mm)
7.54
(191.5mm)
5.81
(147.6mm)
1.62
(41.1mm)
8.08
(205.2mm)
1.60
(40.6mm)
7.88
(200.2mm)
5.75
(146.1mm)
