21
Appendix A
Technical Specifications
The following are the technical specifications for the LabelMANAGER PC printer.
Print Method Thermal Transfer
Print Resolution 180 dots per inch (7.09 dots per mm)
Print Speed 0.4 inch per second (10 mm per second)
Maximum Print Height 0.53 inch (13.54 mm)
Maximum Tape Width 0.94 inch (24 mm)
Computer Interface USB 1.1
Dimensions
2.5” x 5.25” x 5.25”
(63.5 mm x 133.4 mm x 133.4 mm)
Power Requirements 9 V DC, 1.3 A
Ambient Temperature 0˚ C to 40˚
Humidity 10% to 90% RH non-condensing
Weight 1 pound, 1 ounce (0.5 kg)
Print Head Life
Minimum 200 cassettes (7 meters each)
4,590 feet (1.4 km) of label tape
Regulatory Approvals
Printer: CE, FCC
Power Adapter: UL, approved by TUV according to GS standard
Warranty One Year Limited
