Micro800™ 4 Ch Universal Analog Input Module 10
Publication 0100189-02 Rev. A
Module Input Data
There are four input registers used to report data values for each of the
four channels and one register to report CJC sensor temperature.
Table 3 (Module Input Data)
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Ch0 Channel 0 Input Data
Ch1 Channel 1 Input Data
Ch2 Channel 2 Input Data
Ch3 Channel 3 Input Data
CJC CJC Temperature in degrees C
Three separate status bytes are available to the user, one for open-
circuit detect, one for over/under range detection, and one for general
module status.
Table 4 (Open-circuit Status)
Bit 7 6 5 4 3 2 1 0
NU NU O_CJC U_CJC OC3 OC2 OC1 OC0
Bit 0 for channel 0 open wire.
Bit 1 for channel 1 open wire.
Bit 2 for channel 2 open wire.
Bit 3 for channel 3 open wire.
Bit 4 is for CJC under range indication.
Bit 5 is for CJC over range indication.
Bit 6 and Bit 7 are not used.
Micro800™ 4 Ch Universal Analog Input Module 15
Publication 0100189-02 Rev. A
Power consumption <22 mA at 3.3V, <18 mA at 24V, <1.5 W
Inrush current <120 mA at 3.3V, <120 mA at 24V
Fusing 2.7Ω 1/10W resistor on 24VDC input, 0.47Ω 1/10W
resistor on 3.3VDC input
Fault detection Over/under range for all types, open circuit in voltage,
RTD, resistance ranges shown as over-range
Input filters 4 Hz, 17 Hz, 60 Hz, 470 Hz
Wire size #16 to #30 AWG
Operating temperature -20 ºC to 65 ºC
Storage temperature -45 ºC to 85 ºC
Operating humidity 5% to 95% (non-condensing)
Agency approvals / evaluations UL/cUL 508 Ansi/ISA 12.12.01 (Class I, Div 2, T4A)
Manufacturing RoHS and REACH compliant
Dimensions 58.4mm x 29.3mm x 25mm
Environmental Specifications
Environmental Tests Industry Standards Test Level Limits
Temperature (Operating)
(Performance Criteria A)
IEC60068-2-1: (Test Ad, Operating Cold),
IEC60068-2-2: (Test Bd, Operating Dry Heat),
IEC60068-2-14: (Test Nb, Operating Thermal Shock)
-20 to 65°C (-4 to 149°F)
Temperature
(Non-operating)
(Performance Criteria B)
IEC60068-2-1:
(Test Ab, Unpackaged Non-operating Cold),
IEC60068-2-2:
(Test Bb, Unpackaged Non-operating Dry Heat),
IEC60068-2-14:
(Test Na, Unpackaged Non-operating Thermal Shock)
-40 to 85°C (-40 to 185°F)
Operating Altitude 2000 meters (6561 feet) Not tested
Humidity (Operating)
(Performance Criteria A)
IEC60068-2-30:
(Test Db, Unpackaged Damp Heat):
5 to 95% non-condensing
Vibration (Operating)
(Performance Criteria A)
IEC60068-2-6: (Test Fc, Operating)
5G @ 10 to 500 Hz, 0.030 in. max.
peak-to-peak
Shock (Operating)
(Performance Criteria A)
IEC60068-2-27: (Test Ea, Unpackaged Shock)
30 g,11ms half-sine (3 mutually
perpendicular axes)
Shock (Non-operating)
(Performance Criteria B)
IEC60068-2-27: (Test Ea, Unpackaged Shock)
50 g, 11ms half-sine (3 mutually
perpendicular axes)
Radiated Emissions
CSIPR 11; Group 1, Class A
Rockwell Document QTP#X0327 (Enclosure) Class A, 30MHz –
1GHz
Conducted Emissions
IEC 61000-6-4:2007
Rockwell Document QTP#X0327 Group 1, Class A (AC Mains),
150kHz – 30MHz
ESD immunity
(Performance Criteria B)
IEC 61000-4-2
Rockwell Document QTP#X0327
2kV Indirect (Coupling Plate)
2kV Contact Discharge (to points
