INSTRUCTIONS & PARTS LIST FOR RT8AS SERIES ROUTERS
Read and understand "Safety Instructions For Air Tools" and these instructions before
operating this tool.
AIR SUPPLY
The efficiency of the tool is dependent on the proper supply of clean dry air at 90 psig (6.2 bar). The use of a line filter,
pressure regulator, and lubricator will insure maximum output and life of tools. Before connecting tool, blow out the air line to
remove water and dirt which may have accumulated.
HOSE AND HOSE CONNECTIONS
Supply hose should be not less than 3/8" (10mm) I.D. Extension hoses should be at least 1/2" (13mm) I.D. Use couplings and
fittings with at least 3/8" (10mm) I.D.
LUBRICATION
Use SIOUX No. 288 air motor oil. An airline lubricator, set to deliver 2 to 3 drops per minute, is recommended. If a lubricator is
not used, add .08 oz. (2.4 cc, 24 to 30 drops) of oil into the air inlet every 2 to 3 hours.
GENERAL OPERATION
•
The tool may be equipped with a lock-out type lever in order to prevent accidental startup.
•
Speed of the tool may be adjusted by turning the speed control, which is located under the lever.
•
For best results, the direction of the tool travel is generally from left to right.
•
It is recommended that movement be counterclockwise on outside curves and clockwise on inside curves. The tool spindle
rotates clockwise.
CHANGING CUTTING BITS
1.
Disconnect tool from air line.
2.
Remove nose piece assembly.
3.
Hold collet stationary with a 9/16 (14.3 mm) wrench. Loosen collet retaining nut with 11/16 (17.5 mm) wrench.
4.
Insert bit into collet to desired depth. Tighten colet securely. Replace nose peice assembly.
ADJUSTMENTS
1.
Base plate may be adjusted to expose desired length of cutter edge by loosening the lock nut and rotating the nose.
SOUND AND VIBRATION READINGS
*Sound Pressure
*Sound Power
*Vibration
Catalog No.
dBA
dBA
m/s
2
RT8AKS23N
81.64
92.86
Less than 2.5
RT8AKS18N
84.18
96.25
Less than 2.5
*per PN8NTC1
*per PN8NTC1
*per ISO 8662
DECLARATION OF CONFORMITY
We, Sioux Tools, Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, declare under our sole responsibility
that the products
RT8AKS23N, RT8AKS18N
to which this declaration relates are in conformity with the following standard or standards or other normative document or documents:
EN 792, EN 292 Parts 1&2, ISO 8662, Pneurop PN8NTC1
following the provisions of
89/392/EEC as amended by 91/368/EEC & 93/44/EC Directives.
Signature of issuer
June 1, 2006
Murphy, North Carolina, USA
Date and place of issues
Mark S. Pezzoni
President
Power and Specialty Tools
Name and position of issuer
