Page 9
9
1.
57250
Screw—Chuck Retainer
2. 21019A
Chuck—1/4" Capacity (1410R, 1412R)
30202
Key—Chuck (1410R, 1412R)
21077
Chuck—1/4" Capacity (1410AR)
30000
Key—Chuck (1410AR)
3.
67217
Retainer
4.
67552
Washer—Spring Wave
5.
67954
Spacer—Chuck
6.
67841
Assembly—Planetary Reduction (1410R)
(Includes Figures 7 thru 12)
67842
Assembly—Planetary Reduction(1412R)
(Includes Figures 7 thru 12)
7.
67216
Bearing—Ball
8.
67215
Washer
9.
30453
Pin (2)*
10.
19212
Gear—ldler (1410R)(2)*
19195
Gear—Idler (1412R)(2)*
11.
67839
Carrier—Gear (1410R)
67840
Carrier—Gear (1412R)
12.
25680
Washer
13.
10241
Bearing—Ball
14.
19189
Gear—Ring
15.
66132
Pin
16.
65999
Assembly—Motor (Reversing)(6 Tooth)(2000
RPM)(1410R)
66000
Assembly—Motor (Reversing)(8 Tooth)(2600
RPM)(1412R)
17.
65998
Bearing—Ball
18.
65995
End Plate—Lower
19.
14391
Ring—“O”
20.
65994
Cylinder (Reversing)
21.
65991
Rotor (6 Tooth)(1410R)
65992
Rotor (8 Tooth)(1412R)
22.
66190
Vane (Set of 5)
23.
65997
End Plate—Upper (Reversing)
24.
10255
Bearing—Ball
25.
66297
Screw—Retaining
26.
21441
Spring
27.
66021
Valve
28.
66299
Pin—Groove
29.
66246
Plug—Housing
30.
14312
Ring—“O”
31.
21441
Spring
32.
66300
Assembly—Trigger
33.
14349
Ring—“O”
35.
21542
Ring—Retaining
36.
14311
Ring—“O”
37.
66245
Sleeve—Trigger
38.
68461
Trigger
41.
66771
Housing (Reversing)
42.
67399
Seat—Valve
43.
14312
Ring—“O” (2)*
44.
04252
Ring—“O”
45.
66251
Assembly—Valve
46.
66294
Spring—Tapered Compression
47.
66244
Adapter—Inlet
48.
14378
Ring—“O”
49.
30463
Screen**
50.
21541
Ring—Retaining**
51.
65082
Pad—Silencer (Reversing)
52.
66243
Deflector—Exhaust
53.
14378
Ring—“O”
54.
43223
Hose—1/4" Air
55.
30462
Screen
56.
66537
Assembly—Exhaust Hose Exhaust
65505
Cable Ties (4 per package)(Not Shown)
57.
68340
Grip
COMPLETE ASSEMBLY:
66239
Assembly—Housing (Reversing)(Includes
Figures 25 thru 53)
**
These parts can also be replaced by part no.
PSG1-11—screen.
* Order Quantity As Needed
Furnish Catalog, Serial, and Model Number When Ordering Parts
Fig. Part
No.
No.
Description
Fig. Part
No.
No.
Description
PARTS LIST FOR 1410R, 1410AR, & 1412R AIR DRILLS
SERIAL “C”
Remote
Exhaust
