6

©2008 Diamond Audio Technologies. All rights reserved.

THIELE/SMALL PARAMETERS

COMPONENT SYSTEM CONNECTION

The illustration below shows how to connect one channel of the D1 component system.

Crossover

Mid-bass Driver

Tweeter

Amplifier

Parameter (unit)

D161.5

D171i

D191i

Sensitivity

85.0

85.0

83.0

Qts

1.0

1.3

1.4

Fs (Hz)

62

76

58

Vas (L)

11.7

9.3

16.0

Re (ohm)

3.6

3.5

3.6

Xmax (mm/N)

1.5

2.0

1.5

Impedance (ohm)

4

4

4

Power Nom/Max (Watts)

D151i

86.0
0.84

77

5.2
3.6
1.5

4

40/80

50/100

D161.5i

86.0

1.0

67

10.6

3.6
1.5

4

50/100

50/100

70/140
