5350A 1/2" Air Impact Wrench with
Friction Ring Anvil
5350AP 1/2" Air Impact Wrench with
Pin Anvil
Ref. No. Part No. Description Ref. No. Description Part No.
26 506577 O-Ring
27 506578 Oil Seal
28 506579 Ball Bearing
29 506580 Gasket
30 506581 Hammer Cage
31 506582 Hammer Dog (2)
32 506583 Hammer Pin (2)
33 506584 Anvil (5350A)
34 506586 O-Ring (5350A)
35 506587 Socket Retainer (5350A)
36 506588 Anvil Bushing
37 506589 Hammer Case Assembly
38 506590 Washer
39 506591 Seal
40 506593 Gasket
41 506594 Washer
42 506547 Dowel Pin
43 506595 O-Ring
44 506549 Washer
45 506596 Muffler Cover
46 506585 Anvil (5350AP)
47 506697 Pin (5350AP)
48 506598 Spring (5350AP)
49 506599 Screw (5350AP)
1 506553 Housing Assembly
2 506554 Screw Assembly
3 506555 Valve Seat
4 506556 Throttle Valve
5 506557 Valve Spring
6 506558 Exhaust Deflector
7 506559 Air Inlet Bushing
8 506560 Spring Pin
9 506513 O-Ring
10 506561 Trigger
11 506562 Reverse Switch
12 506563 Screw
13 506517 Spring
14 506564 Steel Ball
15 506566 Cap Screw (4)
16 506567 O-Ring
17 506568 Reverse Switch
18 506569 Reverse Bushing Assembly
19 506570 Gasket
20 506571 Ball Bearing
21 506572 Cylinder Assembly
22 506573 Retainer Ring
23 506574 Rotor
24 506575 Rotor Blade (6)
25 506576 Front End Plate
