30
PARTS LIST FOR
RO2512 SERIES RANDOM ORBITAL SANDERS
SERIAL “A”
Fig. Part
No. No. Description
*Order Quantity As Required
FURNISH CATALOG, SERIAL, AND MODEL NUMBER
WHEN ORDERING PARTS
Fig. Part
No. No. Description
1. RO25-100 Housing Assembly
2. RO25-015 Grip
3. RO25-012 Lever
4. RO25-003 Snap Ring
5. RO25-014 Housing
6. RO25-013 Pin
7. RO25-004 O–Ring
8. RO25-005 Valve Stem
9. RO25-002 O–Ring (2)*
10. RO25-001 Regulator
11. RO25-006 Washer
12. RO25-007 Valve
13. RO25-008 Spring
14. RO25-009 Inlet Bushing
15. RO25-046 Muffler Pad (3)*
16. RO25-047 Muffler Screen
17. RO25-037 Exhaust Sleeve
18. RO25-101 Motor Assembly, 6", 3/16
RO25-102 Motor Assembly, 6", 3/32
RO25-103 Motor Assembly, 6", 3/8
RO25-104 Motor Assembly, 5", 3/16
RO25-105 Motor Assembly, 5", 3/32
RO25-106 Motor Assembly, 5", 3/8
RO25-107 Motor Assembly, 3", 3/16
RO25-108 Motor Assembly, 3", 3/32
19. RO25-017 Snap Ring
20. RO25-018 Bearing
21. RO25-011 Top Rubber Bushing
22. RO25-019 Upper End Plate
23. RO25-099 Rotor Blade Set
24. RO25-021 Rotor
25. RO25-024 O–Ring
26. RO25-023 Cylinder
27. RO25-010 Top Pin (3x14mm)
28. RO25-022 Bottom Pin (3x8mm)
29. RO25-025 Lower End Plate
30. RO25-016 Bottom Rubber Bushing
31. RO25-036 Washer
32. RO25-026 Bearing
33. RO25-027 Fiber Washer (2)*
34. RO25-028 Seal Plate Dust Seal
35. RO25-080 Balancer, 6", 3/16
RO25-081 Balancer, 6", 3/32
RO25-082 Balancer, 6", 3/8
RO25-083 Balancer, 5", 3/16
RO25-084 Balancer, 5", 3/32
RO25-085 Balancer, 5", 3/8
RO25-086 Balancer, 3", 3/16
RO25-087 Balancer, 3", 3/32
36. RO25-029 Rotor Key
37. RO25-030 Snap Ring
38. RO25-039 Double Row Bearing
39. RO25-034 Snap Ring
40. RO25-035 Shaft
41. RO25-070 Lock Ring, Standard
RO25-071 Lock Ring, Fine
RO25-072 Lock Ring, Coarse
42. RO25-073 Shroud, Standard
RO25-074 Shroud, Vacuum
RO25-075 Shroud, Standard
RO25-076 Shroud, Vacuum
RO25-077 Shroud, Coarse Orbit
RO25-078 Shroud, Coarse Vacuum
43. 593 PSA Pad, 5", Standard
593J Hook Pad, 5", Standard
593V PSA Pad, 5", Vacuum
593JV Hook Pad, 5", Vacuum
594 PSA Pad, 6", Standard
594J Hook Pad, 6", Standard
594V PSA Pad, 6", Vacuum
594JV Hook Pad, 6", Vacuum
591 PSA Pad, 3", Standard
591J Hook Pad, 3", Vacuum
592 PSA Pad, 3 1/2", Standard
592J Hook Pad, 3 1/2", Vacuum
Items Not Shown:
RO25-045 Wrench
RO25-TK Tune Up Kit (Includes figures no. 4, 7, 9,
11-13, 19-21, 23-25, 30-34, 36-41)
