810LP Reference Dual-Mono Phono Preamplifier

____________________________________________________________________________________

14

Remote Operation



Figure 8: Remote Operation with 12V Trigger



In figure 8 we have a 810LP Phono Preamplifier,

850P Preamplifier, and 870A Power Amplifier

connected together via their respective 12V triggers;

The two 12V trigger outputs on the 850P are
connected to the 12V trigger inputs on both the

810LP (using a 1/8” mini-jack cable) and 870A.

When you turn on the 850P via remote control (or

its Standby button), both the 810LP and 870A will

turn on automatically. The same rule applies when
you put the 850P into Standby mode.
