610LP Dual-Mono Phono Preamplifier
____________________________________________________________________________________
14
Remote Operation
Figure 8: Remote Operation with 12V Trigger
In figure 8 we have a 740P Preamplifier, 610LP
Phono Preamplifier and 860A amplifier connected
together via their respective 12V triggers; The 12V
trigger output on the 740P is connected to the 12V
trigger input on the 610LP (using a 1/8” mini-jack
cable) and the 12V trigger output on 610LP is
connected to the 12V trigger input on 860A. When
you turn on the 740P via remote control (or its
Standby button), both the 610LP and 860A will
turn on automatically. The same rule applies when
you put the 740P into Standby mode.
