Parts List & Breakdown
The Letter after the UV Bio-Wall model denotes biological or biological and chemical destruction.
Example 1: Model # BIO40 ships with five (5) LMPHGS400 Germicidal only Lamps. This model will only do biological
destruction.
Example 2: BIO50 ships with four (4) LMPHGS400 Lamps and one (1) LMPHGXS400 Lamp. This model will do both
biological & chemical destruction.
G
GX
UV BIO-WALL
INSTALLATION
MANUAL
Model Description
Replacement parts Description
BST120W7 120 volt ballast for BIO40, BIO50, BIO60
BST230W7 230 volt ballast for BIO40, BIO50, BIO60
BST277W7 277 volt ballast for BIO40, BIO50, BIO60
LMPHGS400 T6 High Intensity Germicidal (UVC) 40” Straight UV Lamp for BIO40-G (4 out of 5 for BIO40-GX)
LMPHGS500 T6 High Intensity Germicidal (UVC) 50” Straight UV Lamp for BIO50-G (4 out of 5 for BIO50-GX)
LMPHGS600 T6 High Intensity Germicidal (UVC) 60” Straight UV Lamp for BIO60-G (4 out of 5 for BIO60-GX)
LMPHGXS400 T6 High Intensity Dual Zone (36”-UVC / 4”-UVV) 40” Straight UV Lamp for BIO40-GX 1 lamp out of 5
LMPHGXS500 T6 High Intensity Dual Zone (46”-UVC / 4”-UVV) 50” Straight UV Lamp for BIO50-GX 1 lamp out of 5
LMPHGXS600 T6 High Intensity Dual Zone (56”-UVC / 4”-UVV) 60” Straight UV Lamp for BIO60-GX 1 lamp out of 5
MSC6 Bio-Film Aluminum Foil for BioWall Installation 150 ft Roll x 6 ft
MSC9 Flange for all BIO aluminum support tube. Priced per pair
MSCCON19 Connector for aluminum mounting support tube part TUBAA66 to Flange MSC9. Priced per pair
TUBAA66 Aluminum mounting tube 66 inches in length
In-duct UV air purifier consist in of 5 - 40" high intensity UV lamps mounted on 5 aluminum parablic reflectors. Ballast box
is mounted outside the duct and includes LED display, lamp out buzzer, dry contact for remote control monitoring.
Available in 120 volt, 220 volt or 277 volt.
In-duct UV air purifier consist in of 5 - 50" high intensity UV lamps mounted on 5 aluminum parablic reflectors. Ballast box
is mounted outside the duct and includes LED display, lamp out buzzer, dry contact for remote control monitoring.
Available in 120 volt, 220 volt or 277 volt.
In-duct UV air purifier consist in of 5 - 60" high intensity UV lamps mounted on 5 aluminum parablic reflectors. Ballast box
is mounted outside the duct and includes LED display, lamp out buzzer, dry contact for remote control monitoring.
Available in 120 volt, 220 volt or 277 volt.
BIO40G or BIO40GX
BIO50G or BIO50GX
BIO60G or BIO60GX
