RTA Products RTA-4805L - Manual (Page 28)

RTA-4805L P.28
B7
20
19
4PCS
6X20 MM L
40
39
23
24
28
B6
Inner silver ball
bearing slide
HUMP
Make sure inner silver ball
bearing slide is at the front
of the slide mount and in
lock position(over the hump),
as shown.
Asegúrese que las balineras
estén hacia el frente como se
muestra.
Align both sides of slide runners
to slide mounts' openings,then
slide all the way in.Apply small
force to insert completely if needed
Alinee los deslizadores en ambos
lados y deslice lenta y firmemente.
Aplique un poco de fuerza si fuera
necesario. 1st 2nd
Carefully slide drawers onto rails and push firmly and evenly until they are completely closed.
Deslice firme pero cuidadosamente las gavetas hasta que queden completamente cerradas.
Use Screws (L) to assemble the Back Structures (39) to the Big Table
Panel (20) and the Corner Table Panel (19).
Use tornillos (L) para ensamblar las Estructuras Posteriores (39) al Panel
de Mesa Grande (20) y al Panel de Mesa Esquinero (19).
SCREWS TORNILLOS
