页 25 – RTA Products RTA-4805L User Manual
Page 25

RTA-4805L
P.25
A7
19
20
4PCS
6X20 MM
L
39
40
Use Screws (L) to assemble the Back Structures (39) to the Big Table
Panel (20) and the Corner Table Panel (19).
Use tornillos (L) para ensamblar las Estructuras Posteriores (39) al Panel
de Mesa Grande (20) y al Panel de Mesa Esquinero (19).
10
11
12
9
8
E
16PCS
6X12 MM
B1
Use Screws (E) to fix the Left Front Connect Tube, Left Back Connect Tube and Right Connect
Tube (10, 11&12) to the Left & Right Frames (8&9). Please pay attention to the position of the
tubes as shown.
Use tornillos (E) para ensamblar el Tubo Conector Frontal de la Izquierda, el
Tubo posterior de conección derecho y el Tubo Conector derecho (10, 11 & 12)
a las estructuras Izquierda y Derecha (8 & 9). Por favor fíjese bien en las
posiciones de los tubos tal como se muestra.
SCREWS
TORNILLOS
SCREWS
TORNILLOS
