Electrical Specifications
Acoustic Operating Principle:
Electro-dynamic pressure gradient
Polar Pattern:
Figure-8
Generating Element:
2.5 micron aluminum ribbon
Frequency Range:
30HZ – 15,000HZ ± 3dB
Sensitivity:
-39dBv Ref 1 v/pa
Self Noise:
<20dB
Output Impedance:
200 Ohms balanced
Rated Load Impedance:
> 1000 Ohms
Maximum SPL:
> 135dB
Output Connector:
Male XLR 3 pin (pin 2 hot)
Power Requirements:
48-Volt phantom only
Supply Current:
4 mA
All Royer monaural microphones are also available in matched pairs.
Mechanical Specifications
High-grade Neodymium magnet assembly in Royer’s patented Flux-Frame
1.5” x 3/16” x 2.5-micron ribbon assembly
Stainless steel internal baffle and dampener
Dimensions:
206 mm L x 25 mm W (8-1/8” L x 1” W)
Weight:
309 grams (10.9 ounces)
Finish:
Dull Satin Nickel or Matte Black Chrome
Accessories:
Protective wood case, protective mic sock, mic clip
Optional Accessories:
Shock mount, pop screen, 10dB pad
Warranty
Lifetime to original owner (repair or replace at Royer’s option)
To learn more about Royer products and their usage, visit our website at www.royerlabs.com .
18
