- 9 -

• To adjust the SM8 mounting angle simply pull the

quick release handle open while supporting the

microphone.

The SM8 can now be freely adjusted through

approximately 190° (depending on cable XLR

connector and method of mounting.)

Once the required angle is achieved the quick

release handle can be pushed close to lock the

rotation.

If additional tension is required, there is a knob on

the opposite side of the quick release handle that

allows for fi ne adjustment of the quick release grip.

Mounting the NTG8

Quick-Release handle

Tension adjustment dial
