- 7 -
• Having ensured that the power supply is set to the
correct voltage you can begin to connect the NTK
to the power supply. Do not connect the power to
the mains before connecting the microphone.
• Connect the male 7-pin plug of the NTK cable to
the 7-pin input socket on the rear of the power
supply.
• Connect the female 7-pin plug of the NTK cable
to the microphone. Ensure that both plugs are
correctly aligned and pushed fi rmly into their
respective sockets.
• Now connect an XLR microphone cable to the
output socket on the rear of the power supply,
taking that output to your mixer/pre-amplifi er.
• We suggest the use of a high quality cable,
preferably with gold plated contacts. Use as short
a cable as possible, as long cables can adversely
affect sound quality.
• Ensure that the NTK is fi xed securely (using the
supplied stand mount, or optional SM2 shock
mount) to a stable microphone stand. The NTK
condenser microphone is a precision instrument
and should be treated with care.
• Now you can connect the power supply to
the mains supply and begin using the NTK
microphone.
Connecting the NTK
