- 6 -
• Ensure that your NTK has been set to the correct
voltage, as used in your country. The NTK can be
used with mains suppliy voltages of between either
110-120V 50/60Hz or 220-240V 50/60Hz.
- To select for 110-120V use, set the voltage selector
to 115V.
- To select for 220-240V use, set the voltage
selector to 230V.
• On either voltage selection the mains fuse (inside
the mains socket) is always to be a T500mA slow
blow fuse.
• The back panel of the NTK power supply has a
microphone output socket, a ground (earth) lift, a
microphone input socket, a voltage selector, and a
mains power socket which also incorporates a fuse.
• The front panel of the NTK power supply has
the mains power on/off switch and a blue LED to
indicate power status.
Before using the NTK
Microphone
output
Power switch
Microphone input
Voltage selector Ground lift
Mains socket & fuse
Power LED
