Your new Compound Miter Saw is DOUBLE-INSULATED to give you added safety. As a result, this saw is equipped
with a two-prong plug which permits you to use any conventional 120 volt electrical outlet with concern for maintaining
a ground connection.
Before connecting the motor to the power source, confirm that the electric current is 120 volts, and that all connections
are making good contact. NOTE: Running the saw on low voltage will damage the motor.
DO NOT EXPOSE THE MACHINE TO RAIN OR OPERATE THE MACHINE IN DAMP LOCATIONS.
Many Delta tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus
5 percent of that shown on the specification plate of the tool. Several models, however, are designed for A.C. current
only. Refer to the specification plate on your tool for proper voltage and current rating.
POWER CONNECTIONS
MOTOR SPECIFICATIONS
1. Carefully remove the machine from the carton. Retain all packing materials until you have inspected and
satisfactorily operated the machine.
2. Place the machine on a firm, level surface with proper support of the workpiece.
3. The 36-312 is shipped with the cuttinghead at 90° and the table rotated 45° right. To release the head and move it to
the operating position, see “MOVING CUTTINGHEAD TO THE UP POSITION” and “MOVING TABLE TO THE 0°
CUT-OFF POSITION” sections in this manual.
UNPACKING
Do not operate this machine until you read and understand the entire instruction manual.
NOTICE: The photo on the manual cover illustrates the current production model. All other illustrations
contained in the manual are representative only and may not depict the actual color, labeling or accessories
and are intended to illustrate technique only.
EXTENSION CORDS
Use proper extension cords. Make sure
your extension cord is in good condition. When using an
extension cord, be sure to use one heavy enough to
carry the current of the saw. An undersized cord will
cause a drop in line voltage, resulting in loss of power
and overheating. Fig. C shows the correct gauge to use
depending on the cord length. If in doubt, use the next
heavier gauge. The smaller the gauge number, the
heavier the cord.
Fig. C
MINIMUM GAUGE EXTENSION CORD
RECOMMENDED SIZES FOR USE WITH STATIONARY ELECTRIC MACHINES
Ampere Total Length Gauge of
Rating Volts of Cord in Feet Extension Cord
0-6 120 up to 25 18 AWG
0-6 120 25-50 16 AWG
0-6 120 50-100 16 AWG
0-6 120 100-150 14 AWG
6-10 120 up to 25 18 AWG
6-10 120 25-50 16 AWG
6-10 120 50-100 14 AWG
6-10 120 100-150 12 AWG
10-12 120 up to 25 16 AWG
10-12 120 25-50 16 AWG
10-12 120 50-100 14 AWG
10-12 120 100-150 12 AWG
12-16 120 up to 25 14 AWG
12-16 120 25-50 12 AWG
12-16 120 GREATER THAN 50 FEET NOT RECOMMENDED
REPLACEMENT PARTS
When servicing, use only identical replacement parts.
POLARIZED PLUGS: To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than the
other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.
Your miter saw is wired for 110-120 volt, 60 HZ alternating current. Before connecting the miter saw to the power
source, make sure the switch is in the “OFF” position.
