DM525™ and DM575™ Series Digital Mailing System Operating Guide
SV62201 Rev. C 12 - 5
Mailing Materials
Envelope Dimensions (refer to the envelope measurement figure on next page)
Minimum 3 in. x 5 in. (76.2 mm x 127 mm) postcard size.
Maximum 10 in. x 13 in. (254 mm x 330 mm) in landscape orientation.
C5 envelopes can be processed when in portrait orientation.
Envelope Flap Depth (refer to the envelope measurement figure)
Minimum 1 in. (25.4 mm)
Maximum 3 in. (76.2 mm)
Envelope Thickness
Minimum 0.007 in. (0.2 mm)
Maximum 5/8 in. (15.9 mm)
Acceptable Envelope Materials Include:
• Standard envelope paper
• Self-mailers
• Tri-fold mail
• Pre-sealed envelopes
Envelope Flap Profiles:
• Commercial (square and baronial)
• Executive
• Monarch
Weight of the Mail Piece • 5 or 10 lbs. maximum for each piece (depending on capacity
of optional scale).
• 1 lb. (16 oz). for systems with optional WOW® module.
Tape Roll Width Either 4 in. (102 mm) or 5 inches (127 mm)
