• Coaxial Digital Input: For connecting the coaxial output from any digital
source, using a coaxial digital cable. Push the “COAX” input button on the front
of the nova125 to listen.
• Optical Digital Input (sometimes called Toslink): For connecting the optical
output from any digital source, using an optical digital cable. Push the “OPT”
input button on the front of the nova125 to listen.
• USB Digital Input: For connecting the USB output from a computer (or other
source component which can output audio via USB) using a USB cable. Push
the “USB” input button on the front of the nova125 to listen.
• Aux Inputs: For connecting analog inputs (CD player, Tuner, Phono preamp) using
RCA interconnects for unbalanced terminals and XLR interconnects for balanced
terminals. Aux input buttons are on the front panel, so push the one that corresponds
to the Aux input you’re using on the back panel.
• Preamp Output: For connecting the variable preamp output of the nova125 to an
amplifier. The left and right cables should connect to the left and right inputs of the
power amp.
• Speaker Output: For connecting your speakers to the nova125 with speaker wire.
Note that the left and right speaker positive (+) and negative (-) terminals on the
nova125 should be connected to the positive and negative terminals of the left and
right speakers.
Connections
7
