Peachtree Audio nova125 - Manual (Page 8)

F
ront P
anel
6
COAX1 USB OPT AUX COAX2
1 2 3 4 5 6 9 10 7 8
Standby Switch: After turning the nova125 on from the back panel (#11 Power On/
Off switch) you can use this button to switch between “on” which displays a blue light
and “standby” which displays a green light. This function can also be controlled by your
wireless remote.
uSB Digital Input: The USB connection takes digital audio content off your computer
and sends it to the internal DAC via I2S configuration.
coaxial Digital Input 1: Coaxial digital connections are common on some CD players,
cable boxes, Sonos modules, the Slim Devices Squeezebox, and a host of other digital
audio sources. Be sure to use a proper digital audio cable for this purpose.
coaxial Digital Input 2: Coaxial digital connections are common on some CD players,
cable boxes, Sonos modules, the Slim Devices Squeezebox, and a host of other digital
audio sources. Be sure to use a proper digital audio cable for this purpose.
optical Digital Input 1: Toslink and fiber optic cable connections are common on some
CD players, cable boxes, Apple products, and other digital audio sources.
aux analog Input: Line level input that is suitable for iPods, CD players, Tuners, etc.
Ir receiver port: Please aim your remote control at this port for best results. It passes
the infrared commands to the nova125 control software.
tube Window: The tube window is really just for show, but we couldn’t resist. There’s
something about the warm glow of a tube and the kind of sound it produces.
Volume control: The volume control is motorized from your remote control and has a
button indicator to allow the user to see levels from a distance.
Headphone Jack: Plug-in activates mute on the nova125. Please see specifications
for compatibility.
The selector buttons on the Front Panel are very straightforward but we have
included additional information for your benefit.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
