T
echnical Specifications
12
• 125 watts per channel < 0.5% distortion into 8Ω
• 220 watts per channel ,0.5% distrortion in to 4Ω
• Stereo Class D Ice amp modules
• Class A output with 6N1P tube in the circuit
• < 50Ω output impedance
• Hybrid tube design using triode (Stereo 6N1P)
• 5V output @ 2.0V input
• Max output: 7V rms / 11.2V peak
• 4 Digital inputs (all transformer coupled)
• 4 Digital inputs (all transformer coupled): 1 USB, 2 Coax, 1 Toslink (optical)
• 1 RCA Analog input
• > 95db SN (system spec)
• Headphone amp: Class A output with 6N1P tube in the circuit
• Suitable for all electro-dynamic headphones
• Frequency response: 20 ~ 50 kHz +/- 0.1dB
• Headphone amp voltage gain: 9dB
• Headphone: Maximum output voltage: 7Vrms
• Headphone: Output impedance: < 30Ω
• Headphone: Maximum output power:
100mW into 8Ω / 300mW into 150Ω / 150mW into 300Ω
• 24/192 ESS 9023 Sabre DAC
• Transformer coupled digital inputs for ground isolation
• 24/192 kHz USB
• Galvanically isolated USB stage
• > 110db S/N
• AC 115v/230v switchable from back panel
• Maximum power consumption: 600W
• Standby power consumption: < 1W
• Dimensions: 111 x 377 x 292 (mm)
4.37 x 14.8 x 11.5 (inches)
• Weight: 7.2 kg
15.89 lbs
