Peachtree Audio iNova - Manual (Page 5)

F r o n t
P a n e l
4
2 3 7 6 8 9 10 4 5 1
Input for iPod: Push to hear the digital signal from an iPod connected to the iPod dock on top of the
iNova.
Standby: The iNova is in standby mode when this button glows red. Push to turn on the iNova; the button will
light up blue. When you are finished listening, push again to return to standby mode.
Digital USB Input: Push to hear music from your connected computer or other USB audio source.
Digital Coax Inputs: Push to hear music from a component you have connected via a digital coaxial
cable, such as a CD player, DVD player, Sonos Zone Player, Logitech Squeezebox or other digital
source.
Digital Optical Inputs: Push to hear music from a component you have connected via a digital optical
cable (toslink), such as a CD player, DVD player, Sonos Zone Player, Logitech Squeezebox, Apple TV
or other digital source.
Infrared Remote Sensor: When using the remote control aim it at this sensor for best results.
Aux Inputs: Push to hear music from an analog source such as an FM tuner, tape deck or CD player
that you’ve connected with stereo RCA cables. (If you want to connect a turntable you may need a phono
preamp - see the Connections page for more information.) To use AUX 2 in Home Theater bypass mode
see the Back Panel page.
Tube window: A blue LED under the tube turns on when the tube is activated. The tube can be bypassed
using the TUBE button on the remote control.
Volume Control
Headphone Output: Standard 1/4” headphone jack. (Use an adapter to connect headphones equipped
with a mini plug.) The audio signal to the speakers is fully muted when headphones are connected.
The lighted rings around the digital input but-
tons will blink until the digital signal is locked
on the DAC.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
