P a r r I n s t r u m e n t C o m p a n y 16
1108P Oxygen Combustion Vessels
Parts
1108P Parts Diagram Key
KEY ITEM DESCRIPTION
A420A
VALVE NEEDLE WITH KNOB
(NOS. 23, 24, 25)
23 407A VALVE KNOB
24 398A LOCK NUT
25 400A VALVE NEEDLE
26 397A COMPRESSION NUT
27 396A OUTLET VALVE BODY
28 7VBCM WASHER MONEL
29 378A PACKING CUP
30 20VB VALVE SEAT PCTFE
31 PA1332RD04 6-32 X 1/4 RHMS
32 840DD2
60" IGNITION WIRE
(2.0" PER USE)
33
1095DD3
ELECTRODE W/ SETSCREW
(1108P/1108BP)
1095DD3CH
ELECTRODE W/ SETSCREW
(1108PCL/1108BPCL)
34 PC1332SC02 6-32 SHSS (ELECTRODE)
35 906DD2 CAPSULE HOLDER
36 43A_SERIES CAPSULE
Complete Assemblies
ITEM DESCRIPTION
AA101A
OXYGEN VESSEL CYLINDER WITH
103A SCREW CAP FOR (1108P)
AA101A4
OXYGEN VESSEL CYLINDER WITH
103A6 SCREW CAP (1108BP)
AA101ACL
OXYGEN VESSEL CYLINDER
OR CHLORINE SERVICE WITH
103A SCREW CAP (1108PCL)
AA101A4CL
OXYGEN VESSEL CYLINDER
FOR CHLORINE SERVICE WITH
103A6 SCREW CAP (1108BPCL)
A416A5
OXYGEN VESSEL HEAD ASSEMBLY
(1108P/1108BP)
A416A5CL
OXYGEN VESSEL HEAD ASSEM-
BLY FOR CHLORINE SERVICE
(1108PCL/1108BPCL)
KEY ITEM DESCRIPTION
1
103A
SCREW CAP
(1108P/1108PCL)
103A6
HEAVY DUTY SCREW CAP
(1108BP/1108BPCL)
2 230A O-RING 2-3/8 ID BUNA-N
3
394A18 OXYGEN VESSEL HEAD , BARE
394A18CL
OXYGEN VESSEL HEAD, BARE
FOR CHLORINE SERVICE
4*
101A
OXYGEN VESSEL CYLINDER
(1108P)
101ACL
OXYGEN VESSEL CYLINDER
FOR CHLORINE SERVICE
(1108PCL)
101A4
OXYGEN VESSEL CYLINDER
(1108BP)
101A4CL
OXYGEN VESSEL CYLINDER
FOR CHLORINE SERVICE
(1108BPCL)
5 395A2 INLET VALVE BODY
6 415A O-RING 7/16 ID BUNA-N
7 238A O-RING 3/16 ID BUNA-N
8 403A CHECK VALVE
9 411A TERMINAL NUT
10 143AC INSULATOR, DELRIN
12 388A SPACER
13 SC1932SC10 SOCKET HEAD SET SCREW
14 655DD ELECTRODE SPACER
15
404A2
DEFLECTOR NUT
(1108P/1108BP)
404A2CH
DEFLECTOR NUT
(1108PCL/1108BPCL)
16
1095DD
ELECTRODE
(1108P/1108BP)
1095DDCH
ELECTRODE
(1108PCL/1108BPCL)
17
1095DD2
ELECTRODE, INSULATED
(1108P/1108BP)
1095DD2CH
ELECTRODE, INSULATED
(1108PCL/1108BPCL)
19 401A SLEEVE INSULATOR
20 96AC ELECTRODE INSULATOR
* Sold as complete assembly, see Complete Assemblies table
