10 EN
The CG location is 21mm back from the leading
edge at the wing root.
This CG location has been determined with the
included 2S 180mAh 7.4V Li-Po battery installed in
the battery cavity.
Balance the model on the underside of each wing
to fi nd the center of gravity.
Adjusting the Center of Gravity (CG)
Control Rates
We recommend using a DSM2/DSMX aircraft
transmitter capable of dual rates. Adjust according
to individual preferences after initial fl ight.
It is normal for linear servos to make noise. Noise is
not an indication of a faulty servo.
To achieve the proper Low Rate settings when
using a programmable DSM2/DSMX aircraft
transmitter, set the low rate value to 70% for the
aileron, elevator and rudder.
NOTICE: Do not set your transmitter travel
adjust over 100%. If the TRAVEL ADJUST is
set over 100%, it will not result in more control
movement, it will overdrive the servo and cause
damage.
High Rate Low Rate
Aileron 100% 70%
Elevator 100% 70%
Rudder 100% 70%
21mm
