OPTI-UPS SS20K33 - Manual (Page 14)

1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
E E
F F
Lifting lugs
Fan
Variable transformer
Fan
Buck-boost transformer
Push botton
Control board
Enclose mounting holes
Main MCCB
Fuse holes
Magnetic contact
Bypass MCCB
MOV
Isoation transformer
Conduit entrance
Conduit entrance
Ventilator filter unit
Waterproof flat lift-and-turn latch
Input/Output teminal board
Page 2
