Ups controls, Front panel controls – OPTI-UPS PS800B User Manual
Page 12
4 PS500B/PS800B
2. UPS
CONTROLS
2.1 External
Views
MODEL: PS500B, PS800B
100/110/120V
Communication
Port
Battery
Backup
Outlets
DIP Switch
Circuit
Breaker
Data Line
Protection
Inlet
Test/Silence
Button
On/Off
Button
Normal Mode
Battery Mode
Front Panel Rear Panel
220/230/240V
Data Line
Protection
Communication
Port
Batt ery
Backup
Outlets
Inlet
Circuit
Breaker
DIP Switch
Test/Silence
Button
On/Off
Button
Normal Mode
Battery Mode
Front Panel Rear Panel
Front Panel Controls
