Page 8
8
POWER
LED3
EDGE
COM
LOCK+
LOCK -
PGOK200 R
ev
. X
C
M_BLK
M_RED
GRN
VAR3
VAR3
VAR1
VAR4
VAR5
VAR6
G
TO Inc.
Tallahassee, FL
CY
CLE
EXIT
SAFETY
COM
CHGR
CHGR
TAMPER
6
7
+ –
POWER
INTERIOR TOP OF
TRANSMITTER
12 Volt Battery or
12Vdc source
Transmitter/Receiver Connections
Wires from Photo Beams
INTERIOR TOP OF
RECEIVER
TAMPER
6
7
1 2
3 4 5
6 7
POWER
ALARM
+ –
1 2
6 7
To + Pos Terminal of Battery
To - Neg Terminal of Battery
Wiring the Photo Beams to Mighty Mule 200 Gate Opener Control
Board.
1. Connect 1 and 2 power terminals
of the transmitter to the 1 and 2
power terminals of the receiver.
2. Connect 1 and 2 power terminals
of the Receiver OR Transmitter to
the battery.
3. Connect 3 and 5 terminals of the
receiver to the COM and SAFETY
terminals on the control board.
