Wiring the Photo Beams to GTO Access Systems GP-SL050, GP-SW050,
GP-SL100 and GP-SW100 Gate Opener Control Boards.
COM COM COM
CY
CLE
SAFETY SHADOW OPEN CL
OSE
STOP OPEN EDGE CL
OSE
EDGE
RUNNING CL
OSED
LED10 LED09
W1
CUT TO USE 3 BUT
TON
ST
A
TION
CY
CLE
SAFET
Y
SHADO
W
OPEN EDGE CL
OSE
EDGE OPEN CL
OSE
ST
OP COM COM COM
TAMPER
6 7
+ –
POWER
INTERIOR TOP OF
TRANSMITTER
12Vdc source
Transmitter/Receiver Connections
Wires from Photo Beams
INTERIOR TOP OF
RECEIVER
TAMPER
6 7
1 2 3 4 5 6 7
POWER
ALARM
+ –
1 2 6 7
To + Pos Terminal of Battery
To - Neg Terminal of Battery
1. Connect 1 and 2 power terminals
of the transmitter to the 1 and 2
power terminals of the receiver.
2. Connect 1 and 2 power terminals
of the Receiver OR Transmitter to
the battery.
3. Connect 3 and 5 terminals of the
receiver to the COM and SAFETY
terminals on the control board.
