Page 7 of 8
1. Locate coil pack one (1) on the driver side front
of the engine. The ECM on 2010 and newer
Camaros does not conatin the signal wire that
is needed for the LPE RPM-002 activation
switch.
2. Remove the coil electrical connector. The
purple wire in pin C of this electrical connector
is the wire that must be used for input signal to
the RPM switch.
3. Connect to this wire using a 2-1 butt connec-
tor or equivalent. Make sure to heat shrink the
wires.
2010-2011 Camaro Instructions
