Page 12 – Lingenfelter L200010000 Lingenfelter Air Oil Vapor Separator Kit v1.1 User Manual
Page 13
Page 12.
Single Oil/Air Seperator PCV Routing LS6,
LS2, LS3 Valley Tray
Driver side Valve cover
Intake Manifold
Throttle Body
Clean Side
Dirty Side
Passenger side Valve Cover
Oil Level
Oil Pan
Check Valve
or
Orifice or
Inline PCV Valve
Orifice
or
PCV Valve
Single Oil/Air Seperator PCV Routing LS1
Valley Pan, External PCV Valve
Driver side Valve cover
Passenger side Valve Cover
Intake Manifold
Throttle Body
Clean Side
Dirty Side
Oil Level
Oil Pan
Check Valve
or
Plug
Orifice
or
PCV Valve
