Cprmeter. vista general, Vista frontal vista posterior, Vista lateral – Laerdal CPRmeter User Manual
Page 80
80
81
CPRmeter. Vista general
Vista frontal
Vista posterior
(esta superficie hacia arriba)
(esta superficie se aplica al paciente)
Botón de encendido/apagado
Indicador luminoso de estado
Área de
pantalla
Cubierta
posterior
Área de
compresión
Área amarilla
para el adhesivo
para el paciente
Guía de
colocación
Membrana de
ventilación
Tornillos de la
cubierta
posterior
Vista lateral
