48
Appendix A: Freeze Dryer Components
Product Service: Domestic 1-800-522-7658, International 816-333-8811
Item Part No. Description
1 7690800 Lid Gasket
2 7532900 Lid
3 7448000 Printed Circuit Board RS232
4 7953800 Motor Fan, 115V
7953801 Motor Fan, 230V
5 7750607 Compressor, 115V, 60 Hz
7750606 Compressor, 230V, 50 Hz
7750605 Compressor, 230V, 60 Hz
6 1302300 Switch
7 7426000 Control Panel Label
8 7445590 Printed Circuit Board
9 7728000 Drain Plug
10 1643600 O-Ring
11 7645904 Drain Hose
12 7373450 Vacuum Hose (Not Shown)
13 1336400 Power Cord 115V 60Hz (Not Shown)
1336500 Power Cord 230V 50Hz EU (Not Shown)
1342100 Power Cord 230V 60Hz (Not Shown)
1332601 Power Cord 230V 50Hz UK (Not Shown)
1332701 Power Cord 230V 50Hz China (Not Shown)
14 7445400 Vacuum Sensor
15 7515300 Temperature Sensor (Not Shown)
16 7304700 Wire Harness, Power, 115V (Not Shown)
7304701 Wire Harness, Power, 230V (Not Shown)
17 7432700 Vacuum Control/Bleed Valve
18 7429700 Moisture Sensor
19 7418400 Wire Harness, Control 115V and 230V (Not Shown)
20 1289320 Circuit Breaker 115V 20A
1289310 Circuit Breaker 230V 10A
21 1289200 Relay – Vacuum Pump 115V
1289100 Relay – Vacuum Pump 230V
22 1289200 Relay-Refrigeration
