Valve assembly (stainless steel chamber) – Labconco Dry Ice Benchtop Freeze Dry System 7522700 User Manual

Page 5

background image

Instruction Sheet 7523200, Rev A C639

5 of 6

Valve Body

Bulkhead N

ut

Valve Assembly (Stainless Steel Chamber)

Knob & Stem

Assembly

Thrust Washer

Gasket
(No grease required)

Bulkhead

Fitting
