14. Appendices
E SERIES Operation Manual rev 2.0.0
23
E 8:2
Channel RSL switch Channel load Power output
Ch. 1 Ch. 2 Ch. 1 Ch. 2 Ch.1 Ch. 2
unused 70 V 70 V 70 V unused 1200 W @ 70 V
70 V 70 V 70 V 70 V 100 W @ 70 V 1100 W @ 70 V
70 V 70 V 70 V 70 V 200 W @ 70 V 1000 W @ 70 V
70 V 70 V 70 V 70 V 300 W @ 70 V 900 W @ 70 V
70 V 70 V 70 V 70 V 400 W @ 70 V 800 W @ 70 V
70 V 70 V 70 V 70 V 500 W @ 70 V 700 W @ 70 V
70 V 70 V 70 V 70 V 600 W @ 70 V 600 W @ 70 V
70 V Lo-Z 70 V 2 ohms 600 W @ 70 V 600 W @ 2 ohms
70 V Lo-Z 70 V 4 ohms 1000 W @ 70 V 200 W @ 4 ohms*
70 V Lo-Z 70 V 4 ohms 900 W @ 70 V 300 W @ 4 ohms*
70 V Lo-Z 70 V 4 ohms 800 W @ 70 V 400 W @ 4 ohms*
70 V Lo-Z 70 V 4 ohms 700 W @ 70 V 500 W @ 4 ohms*
70 V Lo-Z 70 V 4 ohms 600 W @ 70 V 600 W @ 4 ohms
70 V 70 V 70 V 4 ohms 400 W @ 70 V 800 W @ 4 ohms*
70 V 70 V 70 V 4 ohms 300 W @ 70 V 900 W @ 4 ohms*
70 V 70 V 70 V 4 ohms 200 W @ 70 V 1000 W @ 4 ohms*
70 V 70 V 70 V 4 ohms 100 W @ 70 V 1100 W @ 4 ohms*
70 V 70 V unused 4 ohms unused 1200 W @ 4 ohms
70 V Lo-Z 70 V 8 ohms 1050 W @ 70 V 150 W @ 8 ohms*
70 V Lo-Z 70 V 8 ohms 900 W @ 70 V 300 W @ 8 ohms
70 V 70 V 70 V 8 ohms 800 W @ 70 V 400 W @ 8 ohms*
70 V 70 V 70 V 8 ohms 700 W @ 70 V 500 W @ 8 ohms*
70 V 70 V 70 V 8 ohms 600 W @ 70 V 600 W @ 8 ohms
70 V Lo-Z 70 V 16 ohms 1125 W @ 70 V 75 W @ 16 ohms*
70 V Lo-Z 70 V 16 ohms 1050 W @ 70 V 150 W @ 16 ohms
70 V 70 V 70 V 16 ohms 1000 W @ 70 V 200 W @ 16 ohms*
70 V Lo-Z 70 V 16 ohms 950 W @ 70 V 250 W @ 16 ohms*
70 V Lo-Z 70 V 16 ohms 890 W @ 70 V 310 W @ 16 ohms
70 V Lo-Z 4 ohms 16 ohms 1100 W @ 4 ohms* 100 W @ 16 ohms*
70 V Lo-Z 4 ohms 16 ohms 1050 W @ 4 ohms* 150 W @ 16 ohms
70 V 70 V 4 ohms 16 ohms 1000 W @ 4 ohms* 200 W @ 16 ohms*
70 V 70 V 4 ohms 16 ohms 890 W @ 4 ohms* 310 W @ 16 ohms
Lo-Z 70 V 4 ohms 16 ohms 600 W @ 4 ohms 310 W @ 16 ohms
70 V Lo-Z 4 ohms * ohms 1000 W @ 4 ohms* 200 W @ 8 ohms*
70 V Lo-Z 4 ohms * ohms 900 W @ 4 ohms* 300 W @ 8 ohms*
70 V 70 V 4 ohms 8 ohms 800 W @ 4 ohms* 400 W @ 8 ohms*
70 V 70 V 4 ohms 8 ohms 700 W @ 4 ohms* 500 W @ 8 ohms*
Lo-Z 70 V 4 ohms 8 ohms 600 W @ 4 ohms 600 W @ 8 ohms
Lo-Z Lo-Z 4 ohms 8 ohms 600 W @ 4 ohms 300 W @ 8 ohms
70 V Lo-Z 4 ohms 4 ohms 900 W @ 4 ohms 300 W @ 4 ohms
70 V Lo-Z 4 ohms 4 ohms 800 W @ 4 ohms 400 W @ 4 ohms
70 V Lo-Z 4 ohms 4 ohms 700 W @ 4 ohms 500 W @ 4 ohms
Lo-Z Lo-Z 4 ohms 4 ohms 600 W @ 4 ohms 600 W @ 4 ohms
70 V 70 V 8 ohms 16 ohms 620 W @ 8 ohms 310 W @ 16 ohms
70 V 70 V 8 ohms 8 ohms 600 W @ 8 ohms 600 W @ 8 ohms
70 V Lo-Z 8 ohms 8 ohms 600 W @ 8 ohms 300 W @ 8 ohms
Lo-Z 70 V 2 ohms 8 ohms 600 W @ 2 ohms 600 W @ 8 ohms
Lo-Z Lo-Z 2 ohms 4 ohms 600 W @ 2 ohms 600 W @ 4 ohms
Lo-Z Lo-Z 2 ohms 2 ohms 600 W @ 2 ohms 600 W @ 2 ohms
70 V 70 V 16 ohms 16 ohms 310 W @ 16 ohms 310 W @ 16 ohms
