Specifi cations – Krix Tryptix User Manual

Page 3

specifi cations

amplifi er and speaker power ratings

Krix speakers come with a maximum power
rating. The rating gives you a guide to match
the appropriate amplifi er with your speakers.

When the input level to the amplifi er is very
high, as with CD/DVD players, maximum
output power is reached on the amplifi er
before the volume dial is at maximum. When
using a CD/DVD player, maximum output
power can be at approximately 12 o’clock on
the volume dial. Amplifi ers with the volume
level shown on a digital display make it hard to
judge when maximum power is reached. As a
guide, we suggest that you do not exceed zero
on the digital display.

Turning the volume dial past the amplifi er’s
maximum output power will create distortion
(clipping) (see fi gure 1). Inputting a distorted
signal into your speakers over a prolonged
period will damage them. You can damage
a 200 Watt speaker with a 50 Watt/channel
amplifi er delivering a distorted signal just as

easily as you can damage a 50 Watt speaker
with a 200 Watt/channel amplifi er delivering
too much power. Running an amplifi er at
very high volume over a prolonged period can
even damage a compatible speaker/amplifi er
combination. For more information contact
your authorised Krix dealer or visit krix.com.

'JHVSF

.BYJNVN
"NQMJ±FS
0VUQVU

EJTUPSUJPO DMJQQJOHXJMMPDDVSXIFO
NBYJNVNPVUQVUJTFYDFFEFE

PVUQVUBU
MPXMFWFM

PVUQVUBU
GVMMQPXFS

4BGFBSFB

"SFBJOXIJDIEJTUPSUJPOPDDVST

Frequency Range

65Hz - 40kHz in room response

Power Handling

Maximum 100 watts RMS amplifi er power into 4ohms

Sensitivity

88dB for 2.83 volts at 1 metre

Confi guration

Point source dual 4 inch 2-way

Bass Drivers

2 x nominal 100mm (4”) doped paper cones. 25mm (1”) voice coil
wound on high powered aluminium former provides good linearity
and driver control at large cone excursion

Tweeter

26mm (1”), dual concentric diaphragm with wave-guide centre plug
for controlled directivity. Non-refl ective dual chambered magnet
structure for lower distortion

Crossover Point

1.75kHz

Impedance

Nominally 4 ohms

Enclosure Type

Bass refl ex front vented

Dimensions

550mm high x 136mm wide x 118mm deep

Material

5mm ABS, internally braced

Finish

Laquered high gloss paint

Volume

5 litres internal

Weight

3.5kg each
