Indoor DVB-T antenna

Technical data

• Frequency range:

VHF 87.5-230 MHz
UHF 470-862 MHz

• Receiving range:

FM/VHF/UHF

• Amplifier gain:

25 dB

• Compatible signals:

DVB-T, ISDB-T, DMB-T/H, ATSC, DAB/FM radio

• Output level:

100 dBµv

• Impedance:

75 Ω

• Noise figure:

≤3 dB

• Power supply:

via AC/DC adapter (DC 12 V/50 mA)
or DTV set-top box (DC 5 V/40 mA)

• Antenna cable:

2 m - integrated

• Output:

coax male

• LTE filter (4G):

yes

• Dimensions:

128 x 228 x 0.5 mm

• Colour:

black

Package content

• 1x antenna
• 1x suction cup antenna mount
• 1x mounting sticker
• 1x power supply
• Manual

Installation instructions

First, decide how you would like to connect your antenna; it can be installed in two ways:

1. Powered by DTV set-top box via coaxial cable. The DC 5 V output of the set-top box must be turned

on for this way of connection.

2. Powered via AC/DC adapter.

Digital Terr. STB

5 V 40 mA

Amplifier

Amplifier 5 V 40 mA

Digital Terr. STB

AC/DC adapter

12 V 50 mA

TV

TV
