7
* Manual ON/OFF and Learning Button
Press the button to power the Energy Saver Outlets on/off or execute the learning function.
* Circuit Breaker Reset Button
Reset the circuit breaker after a current overload at 15 Amps. Disconnect all equipment before
pressing the reset button.
Electrical Rating 10 A/250 V, 3680 W
Outlets (Total) 6
Always On Outlet 1
Power Save Outlets 5
Surge Suppression (NV) 918J / (OS) 1836J
EMI/RFI Noise Filter 150 KHz ~ 100 MHz / up to 40 dB
Phone Line (RJ11) Protection
Combo Phone Line (RJ11) & Network (RJ45) Protection
Optional Secondary
DSS/COAX Connector Protection
Stand-by power <0.7 W
CMP-POWG21
* 2 “Always-On” Outlets
Provides continuous power for connected devices.
* 5 “Controlled” Outlets
Controlled on/off by USB Transmitter.
* Surge Protection LED
The red indicator light shows that the surge protector is working.
* Power OK LED
The green indicator light shows that the utility power is powering the outlets.
* Blue Light Save ON Indicator
Indicates that the save socket outlets are fed with power.
* Manual ON/OFF and Learning Button
Press the button to power the Energy Saver Outlets on/off or execute the learning function.
* Circuit Breaker Reset Button
Reset the circuit breaker after a current overload at 15 Amps. Disconnect all equipment before
pressing the reset button.
Electrical Rating 10 A/250 V, 2300 W
Outlets (Total) 7
Always On Outlet 2
Power Save Outlets 5
Surge Suppression (NV) 918J / (OS) 1836J
EMI/RFI Noise Filter 150 KHz ~ 100 MHz / up to 40 dB
Phone Line (RJ11) Protection
Combo Phone Line (RJ11) & Network (RJ45) Protection
Optional Secondary
DSS/COAX Connector Protection
Stand-by power <0.7 W
Protection and use:
This product is protected for currents above 10 A on 220 V AC - 240 V AC. Make sure the product is
connected to a safe phase net. The complete housing of this product is safe, but after damage to its
housing, you can no longer use it. It provides easy connections for 230 V AC and USB powered
devices. This product is only for indoor use.
