5. Specifications
19
5.1. Effect on radiometer accuracy
This section of the manual describes the additional inaccuracy introduced by the AMPBOX, in combination with a CMP pyranometer.
(Preset range of 0 to 1600 W/m² = 4 to 20 mA)
The total inaccuracy is the greater of the absolute and basic values.
The basic inaccuracy is < 1 W/m², temperature coefficient is < 0.1 W/m² / °C
The absolute inaccuracy is <0.05 %
(of span) , temperature coefficient is < 0.01% (of span) / °C
For a span of 1600 W/m² this results in an absolute inaccuracy of 0.8 W ±0.16 W/m² / °C
In practice this means that the inaccuracy of the AMPBOX is <1 W/m² (@ 22 °C)
The additional temperature coefficient is <0.16 W/m² / °C.
Current output range 4 to 20 mA
Input voltage range -12 mV to +150 mV
Gain standard 1 mA / 2 mV
Gain adjusted To suit a specific radiometer
Input impedance 10 MΩ
Operating temperature range -40 °C to +85 °C
Current loop power Needs to be supplied by DAQ or PSU
Supply Voltage range 7.2 VDC to 35 VDC
Voltage drop 7.2 VDC
Ingress protection IP66
Temperature dependence of gain Within ± 0.01 % of span/K
Zero drift < ±1 µV/K
Non-linearity < 0.2 %
Update time 440 ms
Inaccuracy, the greater of ± 0.05 % of span or ± 10 µV
Dimensions 64 x 98 x 34 mm
Weight 0.25 kg
Cable diameters 3 to 7 mm
