JUGS Sports Field General Football Machine - Manual (Page 2)

1
ATTENTION,
Coaches and Operators
of the JUGS FIELD GENERAL ™ :
This manual must be kept with the machine
AT ALL TIMES.
Each coach and/or operator
must read and understand the instructions in this manual
BEFORE USING
the JUGS FIELD GENERAL ™ FOOTBALL MACHINE.
Call 1-800-547-6843 or 503-692-1635
if you need additional copies.
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Safety Signs and Labels . . . . . . . . . . . . . . . . . . . . . . 3
Rules for Safe Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Machine Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Transport Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Slide Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operator Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Drills featuring the JUGS FIELD GENERAL ™ can be
found at www.jugssports.com
