4
Hitec Brushless Servo PC Programming Interface
DPC-10
DPC-10 Software Operating Manual
RC Mode Connection RC Mode connection is useful when setting your
servo parameters because it allows you to check the
function with your radio just as if you were operating
your model. You will still need to use your PC to
perform the programming, but you will use your radio
to check the functions.
It is recommended that you connect your DPC-10 in
the following order for proper operation:
1. Make sure your receiver is bound to your
transmitter.
2. Connect DPC-10 to your PC computer.
3. Launch the DPC-10 software.
4. Connect your servo to the DPC-10.
5. Connect your receiver to the DPC-10 and turn on
the power.
6. Turn on your radio.
7. Click on the “Connect” button.
8. Click on “RC Mode.” Once connected, you will get a
message saying “RC mode change is complete.”
You can now operate the servo with your
transmitter.
Basic Mode Connection
