3
Hitec Brushless Servo PC Programming Interface
DPC-10
DPC-10 Software Operating Manual
Section 2
There are two ways to connect your servo to the
DPC-10, Basic Mode and RC Mode. Connections
Basic Mode Connection Basic mode connection allows you to control your
servo from your PC. All parameters are set first, then
loaded into the servo from your PC. Use your PC to
check the functions.
It is recommended that you connect your DPC-10 in
the following order for proper operation:
1. Connect DPC-10 to your PC computer.
2. Launch the DPC-10 software.
3. Connect your servo to the DPC-10 servo port.
4. Connect your battery to the DPC-10 battery port.
Now click the “Connect” button in the DPC-10
software. If your connections are correct, you will see
the following screen.
The following functions can be programmed into the
HITEC BLDC servos using the DPC-10:
1. FAIL SAFE, On or Off.
2. Direction of Rotation.
3. Travel Speed (Slower).
4. Center, End, and FAIL SAFE Point.
5. Dead Band Width.
6. Soft Start.
7. “Save and Open” Parameter File.
8. Load Factory Default Parameter File. Programming Functions
