MEMORY PRESETS – DATA STORE/LOAD
The X1 Touch charger can store up to 5 different charge/discharge profiles
for your convenience. These stored profiles can be recalled quickly without
having to go through the setup process.
1. STORING PRESETS
Enter the Presets menu and touch edit next to the preset you would like to
create. Select the Battery Type, Number of Cells, Operation, Charge Current
and Discharge Current, then touch CONFIRM to save the data and return to
the previous screen.
2. RECALLING DATA
In the PRESET menu, the basic settings of the profiles are displayed. To use
a preset, touch the desired preset settings bar to select it. You will then be
returned to the Main Menu and the setting of the selected preset will be
displayed at the top of the screen. Press start to execute the operation.
ERROR MESSAGES
The X1 Touch incorporates a variety of functions to verify the operation and
the state of the electronics. In the event of an error, the error screen will
display the cause of the error and emit an audible sound.
CHARGER OPERATIONS (cont.)
CONFORMITY DECLARATION
INT. TEMP TOO HIGH
The internal temperature of the unit is too high, terminate the process and
allow the unit to cool down.
EXT. TEMP TOO HIGH
The temperature detected by the external temperature probe has exceeded
the limit set by the user.
DC IN TOO LOW
Input voltage is less than 11V.
DC IN TOO HIGH
Input voltage is higher than 18V.
OVER TIME LIMIT
The charging time has exceeded the maximum charging time set by the user.
OVER CAPACITY LIMIT
The battery capacity has exceeded the maximum capacity set by the user.
REVERSE POLARITY
Incorrect polarity detected.
CONNECTION BREAK
The battery connection has been lost or interrupted.
CELL NUMBER ERROR
The cell number entered during setup is incorrect.
BALANCE CONNECTER
ERROR
The balance connection is wrong. Check the connections and try again.
NO BATTERY
There is no battery connected to the charger.
CONNECTION ERROR
There is an error in the battery connection, check connection and try again.
BATTERY WAS FULL
When Charging in balance mode, the charger has detected that the cell
voltages have exceeded the user’s specified voltage.
STATE OF CALIFORNIA PROPOSITION 65 WARNING:
This product contains chemicals known to the State of California to cause
cancer. Use caution when handling this product and avoid exposure to any
electronic components or internal assemblies.
This symbol indicates that when this type of electronic device reaches
the end of its service life, it cannot be disposed of with normal household
waste and must be recycled. To find a recycling center near you, refer to the
internet or your local phone directory for electronic waste recycling centers.
The Hitec X1 Touch satisfies all relevant and mandatory EC directives and FCC Part
15 Subpart B:2008.
This product has been tested to meet the following technical standards:
Test Standards
Title
Result
CE-LVD
EN60335-2-29
For safety of household and similar electrical
appliances
Conforms
CE-EMC
EN55014-1
Electromagnetic compatibility-requirements for
household appliances, electric tools and similar
apparatus - Part 1: Emission
Conforms
EN55014-2
Electromagnetic compatibility-requirements for
household appliances, electric tools and similar
apparatus - Part 2: Immunity-Product family
standard
Conforms
EN1000-3-2
Limits-Limits for harmonic current emissions
(equipment input current < 16A per phase)
Conforms
EN1000-3-3
Limits-Limitation of voltage chargers, voltage
fluctuations and flicker in public low-voltage
supply systems, for equipment with related cur-
rent < 16A per phase and not subject to condi-
tional connection
Conforms
FCC
FCC Part 15
Electromagnetic compatibility (EMC),
Conduction Emission & Radiation Emission
Conforms
