Familiarise yourself with the kit!
MULTIPLEX model kits are subject to continuous material monitoring during production. We hope that you will be
happy with the contents of the model kit. However, we ask you to check all parts (against the parts list) before
using them, as processed parts are non exchangeable. If a part should not function, we will be happy, after
checking the problem, to repair or replace the part. In such a case, please send the part to our model construction
department and do not forget to enclose proof of purchase and a short description of the fault.
We are continuously working on the technical improvement of our models. We reserve the right to modify the
contents of the kit with regard to shape, size, technology, material and features at any time and without notification.
Please understand that information and figures in these instructions cannot form the basis for a legal claim.
Warning!
Remotely controlled models, in particular aircraft models, are not toys in the conventional sense. Their
construction and operation requires technical understanding, at least some practical ability and care as
well as discipline and self-confidence. Faults and carelessness during construction and operation can
result in injury to people and damage to property. Because the manufacturer has no influence over the
correct assembly, maintenance and operation we expressly draw these hazards to your attention.
Additional Products Required for Assembly :
Remote control system
When ordering in North and South America add an “M” in front of the part number
MULTIPLEX receiver PiCO 5/6 UNI 35 MHz A order no. 5 5920
40 MHz A order no. 5 5921
72 MHz order no. 5 5954
or MULTIPLEX receiver Micro IPD UNI 35 MHz A order no. 5 5971
40 MHz A order no. 5 5972
72 MHz order no. 5 5973
MULTIPLEX Servo Tiny S UNI (required 2 x) elevator / rudder order no. 6 5121
MULTIPLEX PiCO- 400 round UNI motor controller order no. 7 2292
Drive Battery:
MULTIPLEX drive battery NiCd 6 / 500 mAh order no. 15 5545
or MULTIPLEX drive battery Permabatt NiMh 6 / 1500 mAh order no. 15 6019
or MULTIPLEX drive battery NiCd 7 / 500 mAh order no. 15 5648
Charging unit:
MULTIcharger 4010 DC order no. 9 2527
Glue:
MULTIPLEX „Zacki leicht verdickt“ order no. 59 2720
MULTIPLEX “Zacki Aktivator” order no. 59 2824
Alternatively, a similar superglue (cyanoacrylate glue) can be used, but do not use a superglue for polystyrene.
Epoxy glues initially provide reasonable adhesion, but if loaded, the hard glue will crack off. The adhesion is
only superficial.
Tools:
Scissors, craft knife, combination pliers, Ø 4-5 mm spike or small round file
Technical data:
wingspan 1370 mm
total length 917 mm
fuselage length 870 mm
weight during flight400 motor series / 6 AA cells approx. 680 g
wing size approx. 24 dm²
wing load approx. 28 g/dm²
RC functions rudder, elevator and motor control
Note: Remove the pages with the illustrations from the middle of the instructions for assembly!
Important information
This model is not made from polystyrene foam. For this reason it is not possible to use white glue or
epoxy glue. Please only use a cyanoacrylate glue, preferably one which is used in conjunction with an
activator (kicker). Please use a cyanoacrylate glue (superglue) of medium viscosity such as „ZACKi leicht
verdickt“ With Elapor®, always spray one side with the activator (kicker) – leave it to dry and cover the
other side with the cyanoacrylate glue (ZACKi). Join the parts together and fix their position immediately.
