27
Serial/Ethernet Communication (SCOM) Interface
IND100084-14
MCC Command Syntax and Functionality Details and Values
Gamma (Calibration) Select
Note:
Available function list differs
between MMD and STD units!
Syntax : 07 FF 4D 43 43 02 24 9D xx zz
Function Examples:
Example "1" : 07 FF 4D 43 43 02 24
9D 31 31
Query "?" : 07 FF 4D 43 43 02 24 9D 3F 23
Reset "R" : 07 FF 4D 43 43 02 24 9D 52 10
Reset "r" : 07 FF 4D 43 43 02 24 9D 72 F0
Where xx = "0" to "2" or "1" to "2"
Where zz = Calculated Checksum
Available functions (MMD):
"0" = Calibration VGA
"1" = Calibration DVI
"2" = No Calibration (default)
Available functions (STD):
"1" = Calibration Mode
"2" = Color Temperature (default)
Power Saving / Up
Syntax : 07 FF 4D 43 43 02 24 9E xx zz
Function Examples:
Example "0" : 07 FF 4D 43 43 02 24
9E 30 31
Query "?" : 07 FF 4D 43 43 02 24 9E 3F 22
Reset "R" : 07 FF 4D 43 43 02 24 9E 52 0F
Reset "r" : 07 FF 4D 43 43 02 24 9E 72 EF
Where xx = "0" to "1"
Where zz = Calculated Checksum
Available functions:
"0" = Sleeping Mode
"1" = Normal Mode (default)
Power Down / Up Syntax : 07 FF 4D 43 43 02 24 9F xx zz
Function Examples:
Example "1" : 07 FF 4D 43 43 02 24
9F 31 2F
Query "?" : 07 FF 4D 43 43 02 24 9F 3F 21
Reset "R" : 07 FF 4D 43 43 02 24 9F 52 0E
Reset "r" : 07 FF 4D 43 43 02 24 9F 72 EE
Where xx = "0" to "1"
Where zz = Calculated Checksum
Available functions:
"0" = Power Off
"1" = Power On (default)
Direct Access
Note:
Not available on STD units.
Syntax : 07 FF 4D 43 43 03 23 A0 xx yy zz
Function Examples:
Example "19" : 07 FF 4D 43 43 03 23
A0 31 39 F5
Query "?" : 07 FF 4D 43 43 02 24 A0 3F 20
Reset "R" : 07 FF 4D 43 43 02 24 A0 52 0D
Reset "r" : 07 FF 4D 43 43 02 24 A0 72 ED
Where xx = "1" to "2"
Where yy = "0" to "A"
Where zz = Calculated Checksum
Available functions ( xx ):
"1" - Hot Key 1
"2" - Hot Key 2
Available functions ( yy ):
"0" - Brightness
"1" - PIP size
"2" - Main source
"3" - Second source
"4" - PIP mode
"5" - Scaling
"6" - Swap
"7" - Test pattern
"8" - LED drive
"9" - Language
"A" - No function (default)
Set Runtime Counter Syntax : 07 FF 4D 43 43 02 24 A1 uu vv ww xx yy zz
Function Examples:
Send "00024": 07 FF 4D 43 43 06 20
A1 30 30 30 32 34 68
Query "?" : 07 FF 4D 43 43 02 24 A1 3F 1F
Where uu = "0" to "9"
Where vv = "0" to "9"
Where ww = "0" to "9"
Where xx = "0" to "9"
Where yy = "0" to "9"
Where zz = Calculated Checksum
Example on Response:
"0" "0" "4" "1" "5" (00415)
PIP, PBP Brightness Control
Syntax : 07 FF 4D 43 43 03 23 A2 xx yy zz
Function Examples:
Example "50" : 07 FF 4D 43 43 03 23
A2 35 30 F8
Query "?" : 07 FF 4D 43 43 02 24 A2 3F 1E
Reset "R" : 07 FF 4D 43 43 02 24 A2 52 0B
Reset "r" : 07 FF 4D 43 43 02 24 A2 72 EB
Increase "+" : 07 FF 4D 43 43 02 24 A2 2B 32
Decrease "-" : 07 FF 4D 43 43 02 24 A2 2D 30
Where xx = "0" to "6"
Where yy = "0" to "F"
Where zz = Calculated Checksum
Max Range: "0" "0" to "6" "4"
Default: "3" "2"
